| Transducers | LF: 1×15’’ / HF : 1×1.4’’ |
| Frequency Range (-6dB) | 55Hz – 20kHz |
| SPL max | 141.5dB |
| Weight | 33,5kg / 73.85lbs |
Description
FRXT 15i is a compact, powerful bi-amplified 2-way loudspeaker, adapted from our acclaimed FRX 15 design to meet the needs of clients requiring high SPL and exceptional performance in professional stadium applications.
Our proprietary X-Comb DSP technology eliminates comb effects, ensuring perfect coupling between FRXT 15i cabinets and creating a coherent wavefront at any location. The enclosure houses a 1.4’’ diaphragm compression driver loaded with a 15’’ neodymium low-frequency transducer and offers two distinct directivity plans.
FRXT 15i can be quickly deployed in any configuration when used with AUDIOFOCUS A Series amplifiers with integral DSP and dedicated presets.
FRXT 15i is custom-built with pride in Belgium and coated in tough, weather-resistant polyurea to safeguard your investment. The cabinet front is protected by a rigid metal grill, backed by acoustically transparent foam.
Features
- Multi-function FoH system
- Optimised for medium throw applications
- Bi-amplified
- Adaptive (rotating) AF horn 80×30°
- X-Comb technology inside
Technical specifications
| Description | 2-way bi-amplified full-range installation constant curvature element |
| Transducers | LF: 1×15’’ HF: 1 × 1.4’’ exit compression driver / voice coil diameter 1.75” |
| Frequency range (-6dB) | 55Hz-20kHz |
| Nominal directivity (-6dB) | 80°x30° Rotatable horn, no tools needed |
| SPL max | 141.5 dB |
| Processing | Dedicated AUDIOFOCUS and Powersoft Armonia presets |
| Rigging | M8 threaded inserts Optional bracket and rigging hardware available |
| Connectors | 2x SPK4 speakON |
| Nominal Impedance | LF: 8ohm HF: 8ohm |
| Watt AES/peak | LF: 600/2400W HF: 80/320W |
| Dimensions (H x W x D) | 680 x 429 x 437 mm 26.77 x 16.88 x 17.20 inches |
| Weight | 33,5kg / 73.85lbs |
| Finish | Highly resistant polyurea coating
|
| Cabinet | High grade birch plywood |
