VENU 12

Compact touring 2-way 12″ bi-amp point source loudspeaker


TransducersLF: 1×12’’ / HF : 1×1’’
Frequency Range (-6dB)50Hz – 20kHz
SPL peak / 1m (measured)135 dB
Weight17.3kg / 38.13lbs
Share this product

Description

The ultimate multi-function workhorse loudspeaker, AUDIOFOCUS VENU 12 is a compact bi-amplified 2-way top unit for PA, parties, cafés, and rental companies. VENU 12 excels as a single top or with a companion subwoofer as a full-range PA system, and even as a monitor solution, delivering excellent return on your investment.

An advanced AUDIOFOCUS A-series amplifier with integral DSP and dedicated presets allows VENU 12 to be quickly deployed in any configuration. Armonia presets are also available for Powersoft amplifiers.

VENU 12 is built in Belgium to the same exacting standards as our pro touring ranges and coated in tough, weather-resistant polyurea to protect your investment.

Features

  • Compact 2-way FoH system
  • Suitable for mobile and portable use
  • Rugged top and side carry handles
  • Mirror monitor configuration
  • Tiltable pole mounts
  • Bi-amplified

Technical specifications

Description2-way bi-amplified full-range point source
Transducers LF: 1×12’’
HF : 1×1’’
Frequency range (-6dB)50Hz-20 kHz
Nominal directivity (-6dB)110°x60°
Rotatable horn
SPL peak (1)135 dB
ProcessingDedicated AUDIOFOCUS A-series SCiO and Powersoft Armonia presets
RiggingAdjustable pole mount and M8 threaded inserts
Optional bracket available
Connectors2 × 4-point speakON
Nominal ImpedanceLF : 8 ohm
HF : 8 ohm
Watt AES/peakLF: 350/1400W
HF: 35/140W
Dimensions (H x W x D)566 x 362 x 357 mm
22.28 x14.25 x14.05 inches
Weight17.3kg / 38.13lbs
FinishHighly resistant polyurea coating

CabinetHigh grade birch plywood

(1) Peak level measured at 1 m under free field conditions using pink noise with crest factor 5

Gll files for Ease and Easefocus

Gll • 4.20 Mo • 06/01/2022

A Series Output Chart
VENU 12

PDF • 2.76 Mo • 17/10/2022

Powersoft Presets
VENU 12

Zip • 15 Ko • 20/12/2022

SCiO Presets
VENU 12

Zip • 43 Ko • 09/01/2023

User Manual
VENU Series

PDF • 9.60 Mo • 13/07/2023
