Description
118Sa is a compact, exceptionally powerful active touring subwoofer, created as a core component of the AUDIOFOCUS ARRoCC constant curvature loudspeaker system.
The subwoofer houses a next-generation 18” neodymium LF transducer. Tetracoil Double Voice Coil technology allows 118Sa to achieve best-in-class SPL for its size while ensuring exceptional efficiency and clarity.
118Sa is equipped with an AUDIOFOCUS A4M SCiO Class-D amplifier module with comprehensive integrated DSP. The amplifier can be remotely monitored and controlled via a browser-based WebUI.
118Sa can be used standalone or stacked and can be flown with CC210Wa and CC210Na cabinets using the ARRoCC flying frame accessory.
All AUDIOFOCUS loudspeakers are built in Belgium by skilled craftspeople and state-of-the-art machinery before being coated in tough, weather-resistant polyurea to safeguard your investment.
Features
- Tetracoil double voice coil for efficiency and clarity
- Exceptional SPL in a compact footprint
- Integral amplifier with SCiO remote software
- Cardioid and end-fire configurations
- Scalable, plug ‘n play system building
- Compatible with ARRoCC rigging system
Technical specifications (Preliminary information)
| Description | High-power active compact 18” subwoofer |
| Transducers | LF: 1 x 18″ with Tetracoil Double Voice Coils |
| Frequency range (-6dB) | 30Hz-60Hz |
| SPL peak (1) | 135 dB |
| Processing | Dedicated AUDIOFOCUS SCiO omni and cardioid presets |
| Rigging | Compatible with ARRoCC flying frame |
| Audio connectors | IN: 1×3-point XLR LINK: 1×3-point XLR |
| Network connectors | 1 x etherCON for control |
| Power connectors | IN: 1×3-point powerCON TRUE1TOP LINK: 1×3-point powerCON TRUE1TOP |
| Nominal impedance | 8ohm |
| Dimensions (H x W x D) | 700 x 580 x 700mm 27.6 x 22.8 x 27.6 inches |
| Weight | 70kg / 154lbs |
| Finish | Highly resistant polyurea coating |
| Cabinet | High grade birch plywood |
(1) Mtone 12 dB crest factor
Technical sheet 118Sa
PDF • 370 Ko • 09/01/2024
SCiO
Connect & Control your amplifiers
AUDIOFOCUS SCiO amplifiers can be securely monitored and controlled anytime, anywhere over the network.
Our intuitive Web UI network manager is web-based, eliminating the need for software downloads, and allows multiple amplifiers to be managed from your preferred device.
The network manager offers the comprehensive processing options you would expect from a high-end system controller.
For more detailed information please visit the AUDIOFOCUS SCiO page.
SCiO WEB CONNECTION QUICK START GUIDE
Note – this Quick Start Guide is for use with products manufactured from July 2022
