| Transducers | LF : 1 x 18″ |
| SPL peak / 1m (measured) | 132 dB |
| Weight | 53.8kg / 118.61lbs |
| Rigging | From 0 to 5° |
Description
B 18i is a compact, powerful LF extension for installed ARES 8i line arrays, enhancing the system’s low end response and directivity. ARES 8i and B 18i unite with S / MTSub Series subs to form a consistent, high performance, 4-way install line array system. B 18i is fully compatible with the ARES 8i rigging system and can be flown alongside, on top of or behind ARES 8i elements, or deployed in ground stack / standalone configurations.
The B 18i houses a long excursion 18″ neodymium driver and combines front diffusion, bass reflex, and transmission line design for ultimate efficiency and performance.
B 18i is built with pride in Belgium and coated in tough, weather-resistant polyurea to safeguard your investment. The cabinet front is protected by a rigid metal grill, backed by acoustically transparent foam.
We recommend AUDIOFOCUS or Powersoft amplifiers for use with B 18i.
Features
- LF extension for ARES 8i
- Flown or ground stacked
- Passive
- Integrated rigging
Technical specifications
| Description | Install LF extension for ARES 8i |
| Transducers | LF: 1 x 18″ |
| Frequency range (-6dB) | 55Hz-100Hz |
| SPL peak (1) | 132 dB |
| Processing | Dedicated AUDIOFOCUS SCiO and Armonia/Powersoft presets |
| Rigging | 0 or 5° inter-cabinet angle positions |
| Connectors | 2 × 4-point speakON |
| Nominal Impedance | 8ohm |
| Watt AES/peak | 600/2400W |
| Dimensions (H x W x D) | 510 x 650 x 705 mm 20.07 x 25.59 x 27.75 inches |
| Weight | 53.8kg / 118.61lbs |
| Finish | Highly resistant polyurea coating
|
| Cabinet | High grade birch plywood |
(1) Peak level measured at 1 m under free field conditions using pink noise with crest factor 5
