| Transducers | LF: 1×8’’ / HF : 1×1’’ |
| Frequency Range (-6dB) | 55Hz – 20kHz |
| SPL peak / 1m (measured) | 131 dB |
| Weight | 10.1kg / 22.26lbs |
Description
The 2-way passive VENU 8x speaker delivers our signature audio quality in a discreet, compact, lightweight format, making it the go-to solution for any short throw sound reinforcement or live monitoring applications. Combined with an AUDIOFOCUS S-series sub the VENU 8x can be used as a small PA system. Rental companies and venues will love VENU 8x’s flexibility and portability.
VENU 8x can be quickly deployed in any configuration when used with AUDIOFOCUS A-354 SCiO, A-704 SCiO, A-1504 SCiO, or A-3004 SCiO amplifiers with integral DSP and dedicated presets. Armonia presets are also available for Powersoft amplifiers.
VENU 8x is built in Belgium to the same exacting standards as our pro touring ranges and coated in tough, weather-resistant polyurea to protect your investment.
Features
- Compact 2-way FOH or monitor system
- Lightweight and portable
- Mirror monitor configuration
- Tiltable pole mounts
- Passive
Technical specifications
| Description | 2-way passive full-range point source |
| Transducers | LF: 1×8’’ HF : 1×1’’ |
| Frequency range (-6dB) | 55Hz-20 kHz |
| Nominal directivity (-6dB) | 80°x80° |
| SPL peak (1) | 131 dB |
| Processing | Dedicated AUDIOFOCUS A-series SCiO and Powersoft Armonia presets |
| Rigging | Adjustable pole mount and M8 threaded inserts Optional bracket available |
| Connectors | 2×4-point speakON |
| Nominal Impedance | 8ohm Passive cross-over network |
| Watt AES/peak | 216 W / 864 W |
| Dimensions (H x W x D) | 430 x 273 x 291 mm 16.77 x 10.82 x 11.41 inches |
| Weight | 10.1kg / 22.26lbs |
| Finish | Highly resistant polyurea coating
|
| Cabinet | High grade birch plywood |
(1) Peak level measured at 1 m under free field conditions using pink noise with crest factor 5
